EZVIZ DP2C Smart Video Doorbell with HD Camera, Indoor Display Monitor & Two-Way Video Intercom
EZVIZ DP2C Smart Video Doorbell – Intelligent Home Security
The EZVIZ DP2C Smart Video Doorbell is designed to enhance home security with smart visitor monitoring and convenient two-way communication. Featuring an HD video camera and indoor display monitor, it helps you see and communicate with visitors before opening your door.
With wireless Wi-Fi connectivity, intelligent night vision, and flexible storage options, the DP2C provides a practical security solution for modern homes and apartments.
| Specifications | |
|---|---|
| Model | CS-DP2C |
| Installation Parameters | |
| Supported Hole Diameter | 16.5 to 50 mm (0.65 to 1.97 inch) |
| Supported Door Diameter | 35 to 105 mm (1.38 to 4.13 inch) |
| Camera Parameters | |
| Sensor | 1/3" Progressive Scan CMOS |
| Lens | 2.0 mm @ F2.2, visual angle (diagonal):155° |
| Day/Night Switch | ICR infrared filter |
| IR Distance | Max. 5m |
| Max. Resolution | 1080p / 2MP |
| Video Frame Rate | 15fps |
| PIR Detection | |
| Angle | 110° |
| Distance | Max. 6m (20 ft) |
| Sensitivity | Adjustable |
| Interface | |
| Storage Interface | MicroSD card slot (max. 512 GB) |
| Audio Input | Built-in high sensitivity microphone |
| Audio Output | Built-in high-power speaker |
| Buttons | Doorbell button, power button, Screen wake up button |
| Network | |
| Face Detection | Does not support |
| Intelligence Alarm | PIR motion detection |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Video Intercom | Local and remote video intercom |
| General Function | Cloud video encryption and image encryption |
| Wireless | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission Rate | 11b: 11Mbps, 11g :54Mbps, 11n :150Mbps |
| General | |
| Screen | 4.3-inch color screen |
| Color | Silver/Golden |
| Operating Conditions | -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
| Power Supply | DC 5V (±10%) |
| Power Consumption | Max. 2.2W |
| Dimension | Screen and Base: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch) |
| Peephole Doorbell: 71 x 71 x 48.3 mm (2.80 x 2.80 x 1.90 inch) | |
| Weight | 302 g (10.65 oz) |
| In the box | |
| In the box | - DP2C Peephole Doorbell |
| - Panel | |
| - Mounting Base | |
| - Power Cable | |
| - Screws × 6 | |
| - Quick Start Guide | |
| Certifications | |
| Certifications | UL / FCC / CE / WEEE / REACH / RoHS |
Key Features
-
HD Video Camera: View visitors with clear video monitoring.
-
Indoor Display Monitor: Check who's at your door from inside your home.
-
Two-Way Video Calling: See and communicate with visitors through supported video-call functionality.
-
Two-Way Voice Intercom: Enjoy convenient communication with visitors.
-
Intelligent Night Vision: Monitor visitors in low-light conditions.
-
Wi-Fi Connectivity: Connect to a compatible wireless network.
-
Flexible Storage Options: Supports local memory card and cloud storage options, subject to device and service compatibility.
-
Flexible Power Supply: Supports battery power and a compatible power adapter, depending on the configuration.
-
Smart Home Security: Suitable for indoor monitoring and home entrance security applications.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | EZVIZ |
| Model | DP2C |
| Product Type | Smart Video Doorbell / Door Viewer |
| Camera | HD Video Camera |
| Display | Indoor Display Monitor |
| Communication | Two-Way Video Call & Voice Intercom |
| Connectivity | Wireless Wi-Fi |
| Night Vision | Intelligent Night Vision |
| Storage | MicroSD Card / Cloud Storage Options |
| Listed Memory Options | 32GB, 64GB, 128GB, 256GB, 512GB or No Card |
| Power Supply | Battery / Compatible Power Adapter |
| Application | Home and Apartment Security |
Why Choose the EZVIZ DP2C?
The EZVIZ DP2C combines visitor viewing, indoor monitoring, and two-way communication in a convenient smart security device. It is ideal for homeowners and apartment residents looking for a modern way to monitor their entrance and communicate with visitors.
Bring smarter security to your doorstep with the EZVIZ DP2C Smart Video Doorbell.
